Dual Channel H.264 Encoder/Decoder

Product by: PESA

  • Overview
  • Flow Diagrams
  • Rear Module

PESA’s XSTREAM C22-OG-T is a highly versatile, dual channel H.264 encoder/decoder device for high definition video processing, audio processing and IP streaming. Encoded streams with definable Program ID's are multiplexed onto an MPEG Transport Stream. Similarly, streams for decoding are demultiplexed from an incoming MPEG Transport Stream according to the user-defined Program ID's.

Each processing channel offers video and audio input and output interface in various signal formats at resolutions up to 1080p/60, through rear panel connectors. The C22-OG-T also accepts input from the host openGear frame sync reference that allows local output video signals to be sync locked for use in broadcast and other high-end video environments.The C22-OG-T can be configured in three modes: dual encoder, dual decoder, and bi-directional encoder/decoder.

An independent audio mixer function is provided for each encoder and decoder that allows the audio associated with the input or output video source to be blended or replaced with a source of local auxiliary audio. All audio processing is dual channel for full L/R stereo or other applications.

The C22-OG-T complies with openGear standards for size, form-factor and power consumption. It occupies 2 slots in the openGear 3 frame which means that a single frame can host 20 channels of encode, decode or an arbitrary mix.

Key Features

  • Rich support for video and audio formats and sources
  • Two processing channels for video and audio – each provides an H.264 encoder and decoder
  • SFP cage offers additonal input output options including Fiber
  • Mixing functions to create custom audio track for each video signal
  • Multiplex up to two program streams onto an output MPEG Transport stream with programmable Program ID's
  • Demultiplex up to two program streams from an input MPEG Transport stream by programming the desired Program ID's
  • HDMI input and output
  • Two line level, analog audio output connections
  • High resolution and bitrate support- up to 1080p60 and 10Mb/s
