OSG-8971 High-density SRT encoder/decoder for SDI up to 12G
The OSG-8971 is an SRT gateway for reliable, low-latency SDI transport over IP. With flexible encode/decode operation and optional UHD support, it is ideal for REMI, cloud production, distributed workflows, and facility interconnect.
Product by: Ross Video Limited
Modern production workflows increasingly rely on flexible transport between facilities, remote venues, cloud environments, and distributed production teams. The OSG-8971 enables these workflows by providing reliable, low-latency SRT transport for SDI signals within the trusted openGear platform.
Designed for REMI production, cloud integration, contribution feeds, return feeds, and facility interconnect applications, the OSG-8971 allows SDI signals to be securely transported across public or private IP networks using the SRT protocol. Its flexible architecture allows each channel to operate independently as either an encoder or decoder, enabling mixed contribution and return workflows within a single card.
The compact openGear form factor delivers high channel density while simplifying deployment, monitoring, and management through DashBoard control and monitoring software. Broad codec support, flexible audio handling, and support for both HD and optional UHD workflows allow the OSG-8971 to integrate into a wide range of modern production infrastructures.
Whether supporting centralized production, remote commentary, cloud-based graphics insertion, or distributed live production environments, the OSG-8971 helps bridge traditional SDI systems with scalable IP-based workflows while maintaining the reliability and operational familiarity expected in professional broadcast environments.
Key Specifications:
- HD/3G SDI: up to 6 channels
- UHD SDI: up to 2 channels with optional license
- Each channel selectable as input or output
- Supported formats: 720p, 1080i, 1080p, and 2160p at 50/59.94 Hz
- Codecs: H.264/AVC and H.265/HEVC
- Video encoding: up to 60 Mb/s for HD, up to 100 Mb/s for UHD
- Audio: 8 channels per stream, expandable to 16 with license
- Transport: SRT, with Caller, Listener, and Rendezvous modes
- Network interface: 10/100/1000 Base-T RJ45
- SDI connectors: HDBNC
- openGear form factor: two-slot rear module, up to 10 cards per 2RU oGx frame
