HDMI 2.0 4K Fiber/Copper Extender over 10 GigE (Model: OG-HDM2.0-FIB-II-Tx)
HDMI 2.0 to fiber transmitter for high-density AV over IP
Product by: Apantac LLC
• openGear OGX card-based form factor
• DashBoard control enabled
• Compatible with Apantac Receivers:
• HDM2.0-FIB-II-R
• HDM2.0-FIB-II-R-Pro
• SDM-FIB-R
• SDM-FIB-R-Pro
• Supports up to:
• 20km with single mode fiber
• 300m on multi-mode fiber
• 80m on CAT6
• Supports HDMI 2.0, HDCP 2.2 & 1.4
• Supports all HDMI 2.0 formats including:
• multi-channel PCM
• Dolby True-HD
• DTS-HD master audio
• Supports Dolby Vision up to 4K60 in genlock mode*
• Supports UHD RGB 4:4:4 8 bit, 4:2:0 10 bit, and 12 bit HDR
• Supports all resolutions up to 594 MHz
• Supports CEC pass-through and RS-232 transfer
• Programmable to scale up or down any resolution between VGA and 4K
• Fit up 20 boards in a frame using high density rear module
• Low power consumption
• 5 year limited warranty
* Does not support Dolby Vision in Scaling Mode
Download Datasheet
